Description
Standard parameters:
ECG:
Lead mode: 5 -lead(R,L,F,N,C)
Lead selection : I,II,III,avR,avL,avF,V
Waveform: 3 and 7 channel selectable
Gain selection: 0.5mm/mv,1mm/mv,2mm/mv
Sweep speed: 6.25mm/s;12.5mm/s;25mm/s;50mm/s
Heart rate range: Adult: 15~300bpm;
Neonate/pediatric:15~350bpm
Accuracy: +1bpm or +1%,whichever is greater
Resolution: 1bpm
Filter: surgery mode:1~20Hz
monitor model:0.5~40Hz
Diagnostic mode:0.05~130Hz
Scaling signal: 1mv,+3%
Protection: withstand 4000VAC/50 voltage isolation against electrosurgical interference and defibrillation
Alarm range: 15~350bpm
S-T segment detecton:
Measurement range: 2.0mV~+2.0mV
Alarm Range: -2.0mV~ +2.0mV
Accuracy: -0.8mV ~+0.8Mv
Error: +0.02Mv
Arrhythmia analysis: YES
SPO2
Measurement range: 0~100%
Resolution: 1%
Accuracy: +2%(70-100%);0-69% unspecified
Alarm range 0~100%
Pluse Rate:
range: 20~300bpm
Resolution: 1bpm
Error: +1bpm or +2%,whichever is greater
NIBP
| Method | Digital Automatic oscillometric |
| Operation mode | Manual/Automatic/continuous |
| Auto measurement time | Adjustable(1~480min) |
| Measurement Unit | mmHg/Kpa selectable |
| Measurement types | Systolic, Diastolic, Mean |
| Measurement tange | |
| Range of Systolic pressure | Adult: 40~270mmHg Pediatric: 40~220mmHg Neonate: 40~135mmHg |
| Range of mean pressure | Adult: 20~235mmHg Pediatric: 20~165mmHg Neonate: 20~110mmHg |
| Range of diastolic pressure | Adult: 10~215mmHg Pediatric: 10~150mmHg Neonate :10~100mmHg |
| Over-pressure protection | Double safety protection |
| Resolution | 1 mmHg |
| Alarm | Systolic.Diastolic,Mean |
RESPIRATION
Method:Thoracic impedance
Measurement range:Adult:7~120rpm;
Neonate/Pediatric:7~150rpm
Apnea alarm: YES,10~40s
Resolution:1rpm
Accuracy:+2rpm
TEMPERATURE
Compatible probe:YSI or CYF
Measurement range:5~50ºC
Resolution : 0.1ºC
Accuracy:+0.1ºC
Refreshing time:about 1
Average measuring time:<10s
